Description

Automatic Fuse Blue Sea 200A – Panel Mount

Blue Sea Waterproof Panel Mount Circuit Breaker

Combines switching and circuit protection in one device*
Simple single lever operation
“Trip Free” design cannot be held “ON” during fault current conditions
Water Resistant
Recessed mounting holes for a clean look
Large clearance around terminal studs, suitable for heavy duty cable lugs
Robust 5/16 M8 connections provide high torque connections
Large lever with vertical/horizontal orientation indicates trip status
Ignition Proof – Safe for installation onboard petrol powered boats

* Do not use as a switch where high inrush currents are expected.

Specifications:

Amperage 200A
Maximum Voltage 48V DC
Mounting Panel Mount
Circuit Breaker Type Thermally responsive Bi-metal blade
Terminal Stud Torque 75 in-lb (8.47 Nm)
Interrupt Capacity 5000A @ 14VDC
3000A @ 28VDC
1500A @ 48VDC
Minimum Operating Temperature -40° C
Maximum Operating Temperature 85° C
Case Material Thermoset Polyester
Circuit Breaker Class Type III – switchable/manual reset – trip free
Mounting Hole Accept #10 (M5) Screw
Terminal Stud Size 5/16″ – 18
Weight 0.5lb (0.23kg)
Weight 0.50lb (0.23kg)
